# DAC Exo6: La Circulation

#ConcurrentProgramming #Simulation #WIP

Globally defined variables
Semaphores {} = {}
Integers {} = {}
Changement Traversee1 Traversee2

## Warnings

```    - You must declare `feu` as `{1, 2}` (see the Problem section).

- For technical reasons, you need to call `sleep(0)` if you're going to use an "active wait" loop of some kind that does not contain any call to our predefined functions.

- The 'stop' and 'restart' functionalities are not fully implemented and so you will need to refresh the page to test different algorithms (TO BE FIXED later~).
(You can still call `Sim.stop()` from the console and it will kinda work.)

- Keep this in mind if you're using loops and conditionals:
Sorting each road's vehicles with multiple dynamic queues (semaphores) is tricky. The ordering priority I used depends on calls to p(..);
e.g. `p(sFeu); p(sVide);` creates `orderVec=['sFeu', 'sVide']` that will be used to sort each vehicle in each road.
```

## Problem / Exo

```    EN FRANÇAIS: Exercice 2. Synchronisation : la circulation (#archivé)

Traffic Lights:
At an intersection, traffic is controlled by traffic lights...

Rules:
- The intersection can contain at most one vehicle.
- Vehicles arrive at both roads in a random manner.
- Traffic lights of each road periodically change color (red or green), and hold that color for a finite period of time.
- The traffic lights controller (Changement) should wait only for the current vehicle at the intersection to leave before changing lights.

For the sake of simplicity, we assume that:
- it is an intersection of two one-lane roads
- vehicles don't change direction, and keep moving in a straight line

This system can be modeled as a set of parallel processes:
- A process P that executes the Changement procedure which handles both traffic lights.
- A process for each vehicle (Traverseei if on voiei; where i = {1, 2})
- Traffic light of voiei is green when `feu == i`.
(Hint: Traffic lights display a yellow circle when 'Changement' is blocked on a semaphore)

Predefined functions: `p(sema)`, `v(sema)`, `sleep(secs)`, in addition to Traversee's `circuler()`.

Write Changement, as well as the Traversee1 and Traversee2 procedures to synchronize the system using semaphores.

Gambatte~
```

## Notes

```    This web app is supposed be useful (as in [2]) to students, so they can actually test their algorithms and see how they work in a dynamic system,
and not just a viz like I did with DAC Exo3.

* Why? Why not. Also, because the idea of simulating a dynamic system sounded cool (my DAC teacher mentioned it).

* It makes use of:
- JavaScript's `with` feature which is deprecated and very discouraged
- AsyncFunction
- Promise
- SillySemaphore: My stupid Promise-based and queue-based semaphore
- CSS order
- CSS transition

* Developed and tested with Brave Browser v1.1 (Chromium v79.0)
```

## Refs

These are some of the cool documents and topics I checked while making this...
```    - [1]: Steve Carr and Jean Mayo and Ching-kuang Shene, ThreadMentor: A Pedagogical Tool for Multithreaded Programming (tutorial)

- [2]: B. P. Miller, What to Draw? When to Draw? An Essay on Parallel Program Visualization

- Wikipedia, Queueing theory

- Wikipedia, Taxicab geometry

- Wikipedia, Computer simulation
- Wikipedia, Web-based simulation
- Wikipedia, Discrete-event simulation
- SIM.JS: on Wikipedia, its website

- Traffic Jams in Javascript | bit-player

- Wanis Kabbaj: What a driverless world could look like | TED Talk
```

## Credits

```    - 'City car', 'Truck', 'Traffic lights green', and 'Traffic lights red' icons by Delapouite under CC BY 3.0
```
- @ZEIT's `async-sema` package (under the MIT license) heavily inspired my SillySemaphore
